EXCEL - Damiam Soft-Closing Pull Out Wire Basket

• Material - Made from strips of chromed steel
• Ranges from 400mm - 900mm /
• Drawer panel avg height 200mm



• Max. Weight: 25kg
• Finishing: Polished Chrome
• Evenly-spaced gaps between the strips
• Doubles as an air-dryer
• Running Cover Material: Stainless Steel SUS201

Made from strips of chromed steel for rust prevention when exposed to moisture or water with evenly-spaced gaps between the strips, the Damiam Soft-Closing Pull Out Wire Basket also doubles as an air dryer of sorts to give your dishes that much needed ventilation to prevent odours. It also uses high-quality steel material that is environmentally friendly. Like most products, Excel Hardware gives you a selection of widths to better suit your needs. It ranges from 400mm - 900mm. This product is best used for kitchen and wardrobe cabinets. Set includes: 1 tier Wire Basket, Basket Runner Cover, Screws and Fittings.

Note: To secure the basket to a pull out door, please purchase the brackets separately from this link: excelhw.com.sg/products/drawer-cover-mounting-bracket

Measurements
Basket Size

Item Code E011S-400

Depth	Width	Height	Inner Cabinet
440mm	305mm	130mm	W = 364mm (+/-4mm) D = 480mm+ H = 220mm+

Item Code E011S-450

Depth	Width	Height	Inner Cabinet
440mm	355mm	130mm	W = 414mm (+/-4mm) D = 480mm+ H = 220mm+

Item Code E011S-500

Depth	Width	Height	Inner Cabinet
440mm	405mm	130mm	W = 464mm (+/-4mm) D = 480mm+ H = 220mm+

Item Code E011S-600

Depth	Width	Height	Inner Cabinet
440mm	505mm	130mm	W = 564mm (+/-4mm) D = 480mm+ H = 220mm+

Item Code E011S-700

Depth	Width	Height	Inner Cabinet
440mm	605mm	130mm	W= 664mm (+/-4mm) D = 480mm+ H = 220mm+

Item Code E011S-800

Depth	Width	Height	Inner Cabinet
440mm	705mm	130mm	W = 764mm (+/-4mm) D = 480mm+ H = 220mm+

Item Code E011S-900

Depth	Width	Height	Inner Cabinet
440mm	805mm	130mm	W = 864mm (+/-4mm) D = 480mm+ H = 220mm+

Specifications

• Download Installation Manual
